PL EclCyclorama 100, 330W RGB+warmweiß, 100cm

EclCyclorama 100 is a soft-edge, linear cyclorama and floodlight, designed in a surprisingly low profile form factor to meet applications at both front and end of the stage, offering an unprecedent level of brightness in its category. The fixture is equipped with a custom and calibrated RGB + Warm White LED source, which is capable to deliver a linear and high quality white reproduction of the entire spectrum with high CRI, TLCI and TM30 performances. The optical system has been designed to offer a very wide asymetric beam angle, and capable of a superior lumen efficiency, making the EclCyclorama range a very flexible solution, suitable for both application where fixture are connected each other or separated by a considerable distance, without worrying of dark-edge or uniformity gaps. The fixture is extremely user friendly and offers a multitude of control possibilities being DMX, RDM, Artnet, sACN and Wireless DMX.

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 330W RGB + Warm White
• Luminous flux: (with 40°x80° filter on board) 22'649 @Full
• Lux: @1 m to wall and 1,5 m height @full (with standard filter 40°x80°) 1'240 lx - (with 40° filter) 2'610 lx - (with 10°x60° filter) 3'110 lx - (with 30°x60° filter) 2'880lx
• CRI: 93 @3.200 K; 92,6 @5.600 K
• R9: 88 @3.200 K; 93,7 @5.600 K
• TLCI: 91 @5.600 K
• TM30 Rf: 90,9 @5.600 K
• TM30 Rg: 106 @5.600 K
• Source life expectancy: > 50.000 h

OPTICS

• Beam angle: (VxH) 40°x80°
• Additional optics: see available accessories

COLOUR SYSTEM

• Colour mixing: RGB + Warm White
• CCT: CCT control, + / - green correction, tungsten emulation
• White presets: 2.800 K - 10.000K
• Colour wheel: virtual colour wheel with macros

DYNAMIC EFFECTS

• Control Resolution: 16-bit dimmer, colours
• Special features: linear crossfade channel from any white to any colour; virtual CTO on colours

BODY

• Hardware on-board: sockets for quick-Lock Omega bracket (clamp not included)
• Body: Sturdy die-cast aluminium body
• Body colour: black
• Other: +/- 8° angle adjusting

CONTROL

• Supported Protocols: DMX512, RDM, Art-Net, sACN, W-DMX
• Wireless Control: Included LumenRadio Timo Fx DMX/RDM receiver compatible with CRMX (Lumen Radio) and W-DMX (Wireless DMX)
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)

ELECTRONICS

• Dimmer curves: selectable dimming modes available
• Strobe / shutter: 1 - 30 Hz, electronic
• Operating temperature: -10° ~ +45° Ta
• LED Control: flicker free frequency with adjustable PWM
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 400W
• Standby power: 110V (60Hz): 9,4W; 230V (50Hz): 9,6W
• Power factor: >0,94

PHYSICAL

• IP rating: IP20
• Cooling: heat sink without fan
• Suspension and fixing: any position with quick-lock omega brackets
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Data connection: RJ45 IN/OUT
• Power connection: Seetronic powerCON waterproof IN/OUT connectors
• Dimensions (WxHxD): 1000x119x148mm / 39.37''x4.69''x5.83''
• Weight: 9,6kg / 21.16lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM, cTUVus, FCC

BOX CONTENT

• 1 x ECLCYC100
• 2 x OS25PLUS
• 1 x 1,5 meters 3G1,5mmq power cable (BARE END - SEETRONIC POWERCON TRUE1 IP65 power connector)
• User Manual
