23.483,46 € *

inkl. MwSt. zzgl. Versandkosten

Wenn verfügbar beim Hersteller, Lieferzeit ca. 1-3 Werktage.
* Die aktuelle Lieferzeit kann gerne vorab angefragt werden. Jetzt anfragen.

Artikel-Nr.: 90250055

MAC Ultra Performance 1150 W HIGH OUTPUT LED MOVING HEAD PROFILE WITH FRAMING FEATURES... mehr

Menü schließen

Produktinformationen "Martin MAC Ultra Performance"

MAC Ultra Performance

1150 W HIGH OUTPUT LED MOVING HEAD PROFILE WITH FRAMING

FEATURES

LIGHT SOURCE

1150 W proprietary LED light engine
84 x 20 W white LEDs
Minimum LED lifetime: >50,000 hours (see specs for further details)

PHOTOMETRIC DATA

Light Engine Luminous Output: 90,000 lumens
Fixture Luminous Output: 46,500 lumens
Peak Luminous Intensity: 3,000,000 cd
CCT: 5800 K (+/- 250 K)

OPTICS

160 mm front Lens
1:7 zoom range (8.0° - 54° field angle)
High resolution projection system

DYNAMIC EFFECTS

0 - 100% continuous dimming and strobe effects
Choice of four dimming curves
CMY color mixing
Color temperature control (5800 - 2850 K)
Color wheel with 6 x interchangeable dichroic filters, including Spectral Enhancement Filter
Rotating gobo wheel 1 includes 5 interchangeable gobos + open
Rotating gobo wheel 2 includes 5 interchangeable gobos + open
Gobo animation wheel, indexing, continuous rotation with variable angle
Frost (fade in)
4-facet prism
Iris
Zoom
Focus with auto tracking
Extended Framing module with individual +/- 30° across entire beam and +/- 83° rotation
Pan: 540°
Tilt: 268°
P3 videomapping of fixture color and/or intensity (10 segments)
Pre-programmed effects: Two ranges of pre-programmed FX

COOLING AND NOISE

Low noise cooling system
User-selectable output vs. sound level control

CONSTRUCTION

Height (head straight up): 864 mm (34.1 in.)
Height (maximum): 876 mm (34.5 in.)
Weight: 44.0 kg (97.0 lbs.)

CONTROL

DMX-512 in/out
Ethercon in/out for P3, Art-Net, sACN
Built in Ethernet switch with fail-safe bypass

SPECIFICATIONS

PHYSICALWeight: 44.0 kg (97.0 lbs.)Minimum center-to-center distance in side-by-side installation: 830 mm (32.7 in.)Length (head): 660 mm (26.0 in.)Length (base): 468 mm (15.5 in.)Width (base): 312 mm (12.3 in.)Width (across yoke): 520 mm (20.5 in.)Height (head straight up): 864 mm (34.1 in.)Height (maximum): 876 mm (34.5 in.)

DYNAMIC EFFECTSPre-programmed effects: Two ranges of FX, independent or synchronized/combinedColor mixing: CMY, independently variable 0 - 100%Color wheel: 6 x interchangeable dichroic filters + open (incl. Spectral Enhancement Filter), indexing, continuous rotation, random colorGobo animation: Interchangeable animation wheel, indexing, continuous rotation with variable angle, speed and directionIris: Variable 0 - 100%, pulse effectsFraming: Rotatable framing module, +/- 83°, 4 x individually controllable full curtain blades with full variable angle (+/- 30°) through the entire insertion path from 0 - 100%Prism: 4-facet, indexing and continuous rotationFrost: Variable 0 - 100%, second (heavy) frost available as optional replacement for PrismDimmer/shutter: 0 - 100% continuous dimming, regular and random strobe and pulse effects, instant open and blackoutColor temperature control: Variable 5800 - 2850 KDimming options: Choice of four dimming curvesZoom: MotorizedPan: 540°, coarse & fine control and speedTilt: 268°, coarse & fine control and speedP3: Videomapping of fixture color and/or intensity with variable crossfade between DMX control and video controlFocus: Motorized, range varies with zoom angle, from approx. 4.5 m (14.8 ft.) to infinityRotating gobo wheel 1: 5 x interchangeable gobos + open, indexing, continuous rotation and shakeRotating gobo wheel 2: 5 x interchangeable gobos + open, indexing, continuous rotation and shakeGobo Color Temperature Correction: Automatic

CONTROL AND PROGRAMMINGControl Protocols: DMX, RDM, Art-Net, RDM over Art-Net, sACN and P3Protocol detection: AutomaticDMX channels: Standard 48, Extended 58Setting and addressing: Display Menu, RDM, RDM over Art-Net or P3DMX Modes: Two16-bit Controllable Parameters: Dimming, Color Mixing + CTC, Gobo Rotation/Indexing, Framing, Iris, Zoom, Focus, Pan and TiltFixture Identification: User-settable ID numberDMX compliance: USITT DMX512-ARDM compliance: ANSI/ESTA E1.20Art-Net Compliance: Art-Net 1, 2, 3 and 4; including RDM over Art-NetsACN Compliance: ANSI E1.31 - 2016Martin P3 Compliance: P3 System Controller Software 5.1.0 or newerDMX/RDM Transceiver: Galvanic-isolated RS-485Ethernet Transceiver: 10/100Mbit (with fail-safe bypass)Firmware update: USB memory device, via DMX using Martin Companion or via Ethernet using P3 System ControllerLocal User Interface: Backlit LCD Display with battery-powered operation

OPTICSFront lens diameter: 160 mmZoom range: 8.0° - 54° (1:7 field angle)Light source: 84 x 20 W White LEDs in a custom Martin engineMinimum LED lifetime: >50,000 hours (to >80% luminous output)/ >20,000 hours (to >90% luminous output)*Maximum Total LED Engine Power: 1150 W
*Figure obtained under manufacturer's test conditions

PHOTOMETRIC DATA
Light engine luminous output: 90,000 lumensLED refresh rate : 3000 HzStandardFixture luminous output: 46,500 lumensCRI (Color Rendering Index): 66 (+/- 3)TM-30 Rf (IES TM-30-15 Fidelity Index): 66TM-30 Rg (IES TM-30-15 Gamut Index): 95CCT: 5800 K (+/- 250 K)Peak Luminous Intensity: 3,000,000 cdWith Spectral Enhancement Filter at 5300 KFixture luminous output: 23,500 lumensCRI (Color Rendering Index): 83 (+/- 3)With CTO and Cyan at 3200 KFixture luminous output: 12,000 lumensCRI (Color Rendering Index): 90 (+/- 3)
* All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.

CONSTRUCTIONHousing: High-impact flame-retardant thermoplasticColor: BlackProtection rating: IP20

GOBOSMaximum image diameter: 30 mm (1.181 in.)External diameter: 37.5 mm +0 / -0.2 mm (1.476 in. +0 / -0.008 in.)Maximum gobo thickness: 1.1 mm (0.04 in.)Coating: Heavy matted aluminumMaterial: Borofloat 33

INSTALLATIONMounting points: 2 pairs of 1/4-turn points for 106 mm (4.17 in.) center-to-center omega bracketsLocation: Dry location only, must be fastened to surface or structureOrientation: AnyMinimum distance to combustible materials: 0.2 m (8 in.)Minimum distance to illuminated surfaces: 4.75 m (15.6 ft.)

CONNECTIONSDMX and RDM data in/out: 5-pin locking XLRAC mains power input.: Neutrik TRUE1 socket, accepts TRUE1 NAC3FX-W (TOP) connectorEthernet (Art-Net, sACN and P3) in/out, including fail-safe bypass: Neutrik etherCONFirmware from flash memory: USB 2.0 port

ELECTRICALAC power: 200-240 V AC nominal, 50/60 HzPower supply unit: Auto-ranging electronic switch modeMaximum total power consumption: 1450 WTypical half-cycle RMS inrush current at 230 V, 50 Hz: 17 AMaximum total current at 200 V: 8.0 AMaximum total current at 240 V: 6.7 APower consumption, all effects static, zero light output: 100 W
