PL ArcPod 27VW, 27 x 10W, 15°, IP66, grau RAL7012

ArcPod 27VW is a compact high-power exterior wash light featuring an outstanding brightness of 26'000 lumens and a high quality white reproduction across CCT. It is equipped with 27x10W VW LEDs, delivering a limitless reproduction of whites. ArcPod 27VW is designed slim and fanless, and it's completed by a wide selection of available optics, making the ArcPod 27VW an incredibly flexible and versatile device for any outdoor install.

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 27x10W Warm White + Cold White LEDs
• Luminous flux: (15°) 16'036 lm; (15°+20°) 14'121 lm; (15°+30°) 13'204 lm; (15°+40°) 14'030 lm; (15°+60°) 13'811 lm; (15°+80°) 12'534 lm; (15°+10°x60°) 26'122 lm; (15°+30°x60°) 16'195 @Full
• Lux: (15°) 13'390 lx; (15°+20°) 2'353 lx; (15°+30°) 1'415 lx: (15°+40°) 743 lx; (15°+60°) 492 lx; (15°+80°) 331 lx; (15°+10°x60°) 1'989 lx; (15°+30°x60°) 963lx @5 m full
• CRI: 81,9 @ WW; 84 @ CW; 86,7 @ full
• Source life expectancy: > 50.000 hrs (L70B10 @Ta 25° C / 77° F)

OPTICS

• Additional optics: see available accessories
• Other: barn doors not included

COLOUR SYSTEM

• Colour mixing: tunable white
• CCT: CCT control through dedicated DMX channel
• White presets: 2.700 K ~ 6.500K
• Colour wheel: virtual colour wheel with presets
• Macros: several pre-built macros with adjustable speed

DYNAMIC EFFECTS

• FX generator: up to 3 linear controllable sections
• Static mode: selection of static colour

BODY

• Tilt range: 0 ~ 130° with manual regulation
• Body: Sturdy die-cast aluminium body
• Body colour: RAL 7012 - see available finishing

CONTROL

• Supported Protocols: DMX512, RDM
• DMX channels: 1 / 2 / 3 / 5 / 11 / 11channel
• Pixel control: up to 3 linear controllable sections
• RDM: RDM for remote monitoring and settings
• Display: user interface through DATAMASTER external coder (not included)
• Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Operating temperature: -20° C / +45° C (-4° F / +113° F) Ta
• LED Control: flicker free operation
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 270W
• Output (at 230V): 6 units on a single power line
• Power factor: 0,98

PHYSICAL

• IP rating: IP66 for outdoor installations
• IK rating: 08
• Cooling: natural convection cooling enabled by a fanless design and a chassis engineered for passive heat dissipation
• Adaptors: XLR and BARE END 16A adaptors included
• Signal connection: 1,8 m moulded IP signal IN connector
• Power connection: 1,8 m moulded IP power IN/OUT connectors
• Dimensions (WxHxD): 455x258x83mm / 17.91''x10.16''x3.27''
• Weight: 9kg / 19.84lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM, cTUVus, FCC

BOX CONTENT

• 1 x ARCPOD27VW
• 1 x 1,5 meters 3G1,5mmq power cable (BARE END - IP connection adapter)
• 1 x 5p XLR - IP connection female adapter
• 1 x 5p XLR - IP connection male adapter
• User Manual
