PL EclPendant Jr, 100W, 4.000K, schwarz

The EclPendant Jr is a beautifully designed house light packed with high-performing technology that makes any venue well-lit whilst staying eco-friendly.This innovative series of pendant lights come with a wide selection of LED sources, a full range of optics, accessories, mounting options and control.The EclPendant Jr has a 100-Watt LED source. Its source varies in RGB + Warm White, 3,000K, 4,000K or 5,600K. They all have high-quality light output, a consistent colour temperature and unmatched durability.Several advanced user settings are available from the unit's on-board GUI and control protocols like DALI, DMX + RDM and Wireless DMX (CRMX + W-DMX).The EclPendant Jr was made for several uses - its mounting options include pendant, surface, stem, wall mount, adjustable bracket, and recessed. It's also possible to wire the EclPendant series directly to mains (100-240AC or 48V DC) and DMX or DALI through terminal blocks or feed power and DMX using the TrueOne and DMX connections.The fixture has a wide range of optics and accessories available, with an uncompromising approach to flexibility and precision. All the optics are easily changeable on-site, providing a hassle-free user experience.The EclPendant Jr has a fan-free thermal design and delivers a powerful and consistent lumen output over a long lifespan.NOTE: the hanging bracket does not come with the product

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 100W COB LED
• CCT: see available variants
• Luminous flux: (TU) 6'948 lm; (NW) 7'401 lm; (DY) 7'706 @Full
• Lux: (TU) 1'372 lx: (NW) 1'524 lx; (DY) 1'600lx @5 m full
• CRI: (TU) > 96 - (NW) > 96 - (DY) > 94
• R9: (TU) > 98 - (NW) > 92 - (DY) > 97
• TLCI: (TU) > 95 - (NW) > 97 - (DY) > 97
• TM30 Rf: (TU) > 94 - (NW) > 93 - (DY) > 91
• TM30 Rg: (TU) < 105 - (NW) < 103 - (DY) < 103
• Source life expectancy: > 50.000 hrs (L70B10 @Ta 25° C / 77° F)

OPTICS

• Beam angle: 20°
• Field angle: 40°
• Lens diameter: 122mm / 4.8''
• Lens type: fresnel lens
• Other: see available accessories

COLOUR SYSTEM

• Colour mixing: see available versions

DYNAMIC EFFECTS

• Static mode: selection of static dimmer
• Manual mode: manual adjustment of dimmer and strobe
• Auto mode: built-in programs with execution speed adjustment

BODY

• Body: Sturdy die-cast aluminium body
• Body colour: RAL 9004 or RAL 9010

CONTROL

• Supported Protocols: DALI Type6, DMX512, RDM, CRMX
• DMX channels: UNO / DUO / Standard / Extendedchannel
• Wireless Control: Included LumenRadio Timo Fx DMX/RDM receiver compatible with CRMX (Lumen Radio) and W-DMX (Wireless DMX)
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
• Other: 16bit control of dimmer

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1-30 Hz, electronic
• Operating temperature: -10° ~ +45° Ta
• LED Control: flicker free frequency with adjustable PWM
• Selectable PWM: 600 ~ 40.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Low Voltage DC mains: DC 48V for emergency light use
• Max power consumption: 105W
• Output (at 230V): 24 units on a single power line
• Power factor: > 0,93

PHYSICAL

• IP rating: IP20
• Cooling: Heatsink with heat pipes, natural convection cooling enabled by a fanless design and a chassis engineered for passive heat dissipation
• Suspension and fixing: bracket for hanging and positioning (bracket not included on the product)
• Signal connection: screw terminal block, Amphenol XLR 5p IN/OUT connectors
• Power connection: screw terminal block, Neutrik powerCON TRUE1 IN/OUT connectors
• Low Voltage DC connector: DC 48V through screw terminal block
• Dimensions (WxHxD): 170x321x170mm / 6.69''x12.64''x6.69''
• Weight: 5kg / 11.02lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM, cTUVus, FCC

BOX CONTENT

• 1 x ECLPENDANTJR
• 1 x 1,5 meters 3G1,5mmq power cable (BARE END - SEETRONIC POWERCON TRUE1 IP65 power connector)
• User Manual
• NOTE: no hanging bracket ECLPENDJRHGBRK on board to the fixture

Es sind leider keine Geräte verfügbar.

Es kann vorkommen, dass in unserem Lager noch gebrauchte Geräte vorhanden sind. Fragen Sie gerne über unsere Service-Hotline +49 871 40875521 oder per Email info@lights-whatever.de bei uns nach. Wir helfen Ihnen gerne weiter!
