PL EclProfile Junior ZIP, 160W, 3100K, IP65, ohne Linsentubus

EclProfile JrZIP is an IP rated zoomable ellipsoidal designed for exterior application. EclProfile JrZIP reaches an exceedingly high lumen output of nearly 6'000 lumens, and all in a compact size allowing for use on any outdoor show or for logo and texture projection over buildings. EclProfile JrZIP can use two different manual zoom lenses (optional) being 15° - 30° or 25° - 50° and it can be mounted at any distance from the projection surface.

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 160W Warm White LED
• CCT: (TU) 3.100 K - (DY) 5.500
• Luminous flux: (TU - 50°) 5'274 lm - (TU - 25°) 5'770 lm; (TU - 30°) 4'200 lm - (TU - 15°) 5'012 lm - (DY - 50°) 5'390 lm - (DY - 25°) 4'911 lm; (DY - 30°) 3'844 lm - (DY - 15°) 4'450
• Lux: (TU - 50°) 2'040 lx - (TU - 25°) 5'160 lx; (TU - 30°) 3'710 lx - (TU - 15°) 12'900 lx - (DY - 50°) 1'750 lx - (DY - 25°) 4'530 lx; (DY - 30°) 3'000 lx - (DY - 15°) 11'200lx @3 m
• Lux: (TU - 50°) 734 lx - (TU - 25°) 1'857 lx; (TU - 30°) 1'336 lx - (TU - 15°) 4'644 - (DY - 50°) 630 lx - (DY - 25°) 1'630 lx; (DY - 30°) 1'080 lx - (DY - 15°) 4'032lx @5 m
• CRI: >90
• Other: TLCI: >91 - TM30-15 RE/RF: 97/88
• Source life expectancy: > 50.000 h

OPTICS

• Beam angle: (not included) manual zoom lens 15°-30° or (not included) manual zoom lens 25°-50°
• Lens diameter: 87mm / 3.43''
• Lens type: high-quality glass lens optics
• Focus: manual

COLOUR SYSTEM

• Macros: several pre-built macros with adjustable speed

DYNAMIC EFFECTS

• Gobo size: M, outer: 66 mm - image: 45 mm - thickness: 1,1 mm
• Static mode: selection of static dimmer
• Manual mode: manual adjustment of dimmer and strobe
• Auto mode: built-in programs with execution speed adjustment

BODY

• Hardware on-board: on board mechanics for rigging to the ceiling
• Body: Sturdy die-cast aluminium body
• Body colour: black

CONTROL

• Supported Protocols: DMX512, W-DMX
• DMX channels: 1 / 3channel
• Wireless Control: Included LumenRadio Timo Fx receiver compatible with CRMX (Lumen Radio) and W-DMX (Wireless DMX)
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
• Master/Slave: for synchronised operation of more units linked in a chain
• Other: 16bit control of dimmer

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 - 30 Hz, electronic
• Operating temperature: -20° ~ +45° Ta
• LED Control: flicker free operation
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Max power consumption: 136 W
• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 136W
• Max power consumption (at 120V): 138,6W
• Power factor: pF 0,98 @120 V - pF 0,97 @230 V

PHYSICAL

• IP rating: IP65 for temporary outdoor application, not for fixed installations
• Cooling: active, silent operation
• Suspension and fixing: bracket for hanging and positioning
• Signal connection: Seetronic XLR 5p IN/OUT connectors
• Power connection: Seetronic powerCON waterproof IN/OUT connectors
• Dimensions (WxHxD): 275x440x275mm / 10.83''x17.32''x10.83''
• Weight: 7,9kg / 17.42lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM

BOX CONTENT

• 1 x ECLJZIP
• 1 x 1,5 meters power cable (BARE END - SEETRONIC IP65 power connector)
• User Manual
