PL Ra 2000 Profile, 540W LED, 8°-48°, schwarz

The Ra 2000Profile has been designed in response to feedback from global users and by lighting designers. A universal moving profile/spot that lighting designers and users can use for theatrical, touring and TV productions. Powerful but silent, compact but fully equipped with both framing shutters and animation wheel, all whilst delivering a superior light quality, the Ra 2000Profile is an indispensable tool for any show. The 6.500 K LED engine has been custom engineered to make the Ra 2000Profile hit a 13'900 lumen output, keeping a native CRI of 93, TLCI of 93, high R9 and TM30 making all skin tones and colours come to life on stage or in front of a camera. The Ra 2000Profile's CMY system delivers beautiful pastels, stunning saturated colours and powerful primaries. One colour wheel provides split colours, and linear CTO allows the Ra 2000Profile to blend in with traditional sources. Packed with a full feature set composed of a gobo wheel, adjustable framing shutters, animation wheel, iris, prism and dual linear frost. The highly efficient optical system delivers a 1:6 zoom from 8° to 50°, and crisp focus to perfectly merge multi-layer effects. The Ra 2000Profile is the real embodiment of solid-state LED technology.

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 540W LED
• CCT: 6.500
• Luminous flux: 13'900
• Lux: (8°) 24'537 lx - (50°) 991lx @5 m
• CRI: >93
• R9: >73
• TLCI: >92
• TM30 Rf: >89
• TM30 Rg: >99
• Source life expectancy: > 30.000 hrs (L70B10 @Ta 25° C / 77° F)

OPTICS

• Zoom range: 8° - 50° motorised linear zoom
• Lens diameter: 120mm / 4.72''
• Focus: motorised

COLOUR SYSTEM

• Colour mixing: linear CMY
• CCT: amber shift activation by DMX and linear CTO correction 2700 K ~ 6000 K
• Colour wheel: 6 colour filters

DYNAMIC EFFECTS

• Shutter system: 4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete framing system
• Animation wheel: animation wheel with CW and CCW rotation
• Rotating gobos: 7 rotating gobos + open, interchangeable, indexing
• Gobo size: outer: 26,7 mm - image: 20 mm - thickness: 1,1 mm
• FX generator: shutter macros with adjustable speed
• Circular prism: 4f with bi-directional rotation, indexing
• Frost: dual frost filter system, 1° soft-edge frost gobo, 5° frost wash, with linear 0 - 100% frost filter to soften the beam edge
• Iris: 5 - 100% motorised iris
• Static mode: selection of static colour
• Manual mode: manual adjustment of dimmer and strobe
• Special features: OFF, ON and AUTO setup options for manage red LED

BODY

• Pan range: 540°
• Tilt range: 270°
• Pan/Tilt resolution: bit 16-bit
• Feedback: automatic repositioning after accidental movement
• Body colour: black finishing

CONTROL

• Supported Protocols: DMX512, RDM, Art-Net, sACN, W-DMX
• DMX channels: 38 / 39 / 40 / 41/ 44channel
• Wireless Control: Included Wireless Solution receiver
• RDM: RDM for remote monitoring and settings
• Display: LCD high resolution colour display with autoflip
• Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Strobe / shutter: 1 - 30 Hz, electronic
• Display battery: self-charging battery backup
• Operating temperature: -10° ~ +50° Ta
• LED Control: flicker free operation

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 690W
• Output (at 230V): 4 units on a single power line
• Power factor: >0,96

PHYSICAL

• IP rating: IP20
• Cooling: combination of heat pipe cooling system and low noise fan
• Suspension and fixing: hanging bracket for floor positioning with "Quick-Lock" system
• Pan / tilt lock: for transportation and maintenance
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Data connection: Art-Net RJ45 IN/OUT
• Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
• Dimensions (WxHxD): 443x697x293mm / 17.44''x27.44''x11.54''
• Weight: 32kg / 70.55lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM

BOX CONTENT

• 1 x RA2000PROFILE
• 1 x 1,5 meters power cable (BARE END - NEUTRIK POWERCON TRUE1 IP65)
• 2 x OS25PLUS
• User Manual

Es sind leider keine Geräte verfügbar.

Es kann vorkommen, dass in unserem Lager noch gebrauchte Geräte vorhanden sind. Fragen Sie gerne über unsere Service-Hotline +49 871 40875521 oder per Email info@lights-whatever.de bei uns nach. Wir helfen Ihnen gerne weiter!
