- Artikel-Nr.: CRMXBOXIP67
- Hersteller-Nummer:
The CRMXBox IP67 is an outdoor transceiver designed for permanent exterior installations. Capable of functioning as either a transmitter or receiver, it handles one DMX universe, accommodating up to 512 channels. The unit's compact form factor includes IP-rated screwed connectors for reliable power and signal connections. Its robust construction, featuring an IP67-rated enclosure and a vandal-resistant mounting cover, ensures durability against outdoor elements. The device is user-friendly, equipped with an onboard display and buttons for straightforward setup. It is compatible with Lumen Radio CRMX and Wireless DMX G protocols, offering versatile integration options.
TECHNICAL SPECIFICATIONS
BODY
- Hardware on-board: 5dB antenna included
- Body: Weatherproof IP67 construction with die-cast aluminium alloy
- Body colour: RAL 9006
CONTROL
- Supported Protocols: DMX512, RDM, CRMX
- DMX channels: 512channel
- Wireless Control: Included LumenRadio Timo Fx DMX/RDM receiver compatible with CRMX (Lumen Radio) and W-DMX (Wireless DMX)
- RDM: RDM for remote monitoring and settings
- Display: Graphic User Interface
- Firmware upgrade: via DMX with UPBOXPRO (USB-DMX interface not included)
ELECTRONICS
- Display battery: self-charging battery backup
- Operating temperature: -20° C / +45° C (-4° F / +113° F) Ta
ELECTRICAL
- Mains power supply: 100-240V - 50/60Hz
- Max power consumption: 6W
PHYSICAL
- IP rating: IP67 for outdoor installations
- Suspension and fixing: holes for fixing to surfaces
- Signal connection: moulded IP signal IN (OUT) connector
- Power connection: moulded IP power IN connector
- Dimensions (WxHxD): 238x120x84mm / 9.37''x4.72''x3.31''
- Weight: 1,65kg / 3.64lbs
CERTIFICATIONS / APPROVALS
- Certifications / Approvals: CE
BOX CONTENT
- 1 x CRMXBOXIP67
- 1 x AEB5DBA
- 1 x IP power adapter (bare-end) compatible with AWEXAC1 series
- 1 x IP DMX female adapters (DMX IN) compatible with AWEX1DC series
- 1 x User Manual
