PL Astra Profile900, 900W LED, 7.000K, schwarz

The Astra Profile900 is a flagship, high-power profile moving head designed for large-scale live productions, studios, and theaters. Powered by a 900W LED source, it delivers an impressive 43,000-lumen output (as measured by photogoniometer), making it an exceptional key light for any major production.Its large 185mm front lens and versatile 5°-52° zoom range ensure outstanding performance at virtually any distance. The new MotiOs motion ecosystem enhances speed, precision, and responsiveness across pan, tilt, internal wheels, and framing modules, setting a new standard in motion control.For precise color control, the Astra Profile900 features linear CMY+CTO mixing and a color wheel with a high-CRI filter, delivering vibrant tones and balanced whites. Additional highlights include dual rotating gobo wheels, an animation wheel, a four-layer framing system, dual prisms, dual frost filters, and iris—making it adaptable to a wide variety of production needs.

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 1000W White LED (driven @900W)
• CCT: 7.000K
• Luminous flux: (5,5°) 23'816 lm - (52°) 42'919 lm
• Lux: (5,5°) 126'304 lx - (52°) 3'060lx @5 m
• CRI: > 70 (CCT 6.000K and CRI > 90 with filter on color wheel)
• Source life expectancy: > 50.000 hrs (L70B10 @Ta 25° C / 77° F)

OPTICS

• Zoom range: 5,4° - 52° motorised linear zoom
• Lens diameter: 185mm / 7.28''
• Lens type: HD anti-reflection lenses with achromatic coating
• Focus: motorised 16-bit control with focus tracking

COLOUR SYSTEM

• Colour mixing: linear CMY
• CCT: linear CTO correction 2.700 K ~ 7.000 K
• Colour wheel: open + high CRI filter + 5 colour filters

DYNAMIC EFFECTS

• Control Resolution: 16-bit dimmer
• Shutter system: 4 shutter blades with position and ±30° angle adjustment, ±45° rotation of the complete framing system
• Animation wheel: animation wheel with CW and CCW rotation
• Rotating gobos: 7 rotating gobos + open, interchangeable, indexing
• Gobo size: outer: 30 mm - image: 25 mm - thickness: up to 3 mm
• Rotating gobos: 7 rotating gobos + open, interchangeable, indexing
• Gobo size: outer: 30 mm - image: 25 mm - thickness: up to 3 mm
• FX generator: 2 prisms overlap for spectacular aerial effects
• Circular prism: 4f with bi-directional rotation, indexing
• Linear prism: 6f with bi-directional rotation, indexing
• Frost: dual soft-edge and heavy with one interchangeable element
• Iris: 5 - 100% motorised iris

BODY

• Hardware on-board: sockets for quick-Lock Omega bracket (clamp not included)
• Pan range: 540°
• Tilt range: 270°
• Pan/Tilt resolution: bit 16-bit
• Feedback: automatic repositioning after accidental movement
• Body: Aluminium structure with high-resistance polycarbonate cover
• Body colour: black

CONTROL

• Supported Protocols: DMX512, RDM, ArtNet, sACN, CRMX
• DMX channels: 46channel
• Wireless Control: Included LumenRadio Timo Fx DMX/RDM receiver compatible with CRMX (Lumen Radio) and W-DMX (Wireless DMX)
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: via DMX with UPBOXPRO/UPBOX2 (USB-DMX interface not included) or via USB pen drive
• EtherFlow: Ethernet pass-through switch that preserves network connectivity even when the fixture is unpowered.

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 - 30 Hz, electronic
• Display battery: self-charging battery backup
• Operating temperature: -10° ~ +45° Ta
• LED Control: flicker free frequency with adjustable PWM
• Selectable PWM: 600 ~ 50.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 1310W
• Standby power: 150 W
• Output (at 230V): 2 units on a single power line
• Power factor: > 0,97

PHYSICAL

• IP rating: IP20
• Cooling: combination of heat pipe cooling system and low noise fan
• Suspension and fixing: any position with quick-lock omega brackets
• Pan / tilt lock: for transportation and maintenance
• Signal connection: Neutrik XLR 5p IN/OUT connectors
• Data connection: Neutrik Art-Net RJ45 IN/OUT
• Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
• Dimensions (WxHxD): 516x856x310mm / 20.31''x33.7''x12.2''
• Weight: 45,2kg / 99.65lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, RCM, FCC, cTUVus

BOX CONTENT

• 1 x ASTRAPROFILE900
• 2 x OS30PLUS
• 1 x 1,5 meters 3G2,5mmq power cable (BARE END - NEUTRIK POWERCON TRUE1 IP65 power connector)
• 1 x User Manual
