PL Pixie WashXB, LED Washlight, 280W, 7,6-43°

Pixie WashXB reinvents the concept of the moving LED wash light, bringing together the classic styling of a traditional wash luminaire and applying the very latest innovations in the field of LED technology. The large frontal plano-convex lens delivers a stunning level of brightness and an exceptional zoom range with a 1:8 ratio, combined with a proprietary 280W RGB and warm white LED module delivering a high-quality white reproduction with high CRI and TLCI parameters as well an extremely precise colour tuning. Pixie WashXB is an ideal solution for any application where users want a superior light quality but without the view of multi-cell fixtures. Being compact, fast and silent, the Pixie WashXB offers unprecedented flexibility and is ideal for use in theatres, TV, corporate and festivals.

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 280W RGB + Warm White LED
• CCT: @full 6.000
• Luminous flux: (7,6°) 2'888 lm - (43°) 3'038 @Full
• Lux: (7,6°) 6'631 lx - (43°) 532lx @5 m full
• CRI: 96 @3.200 K; 93 @5.600 K
• R9: 92 @3.200 K; 92,7 @5.600 K
• TLCI: 84 @3.200 K; 84 @5.600 K
• TM30 Rf: 91 @3.200 K; 91 @5.600 K
• TM30 Rg: 104 @3.200 K; 105 @5.600 K
• Source life expectancy: > 30.000 h

OPTICS

• Zoom range: 7,6° - 43° motorised linear zoom
• Lens diameter: 125mm / 4.92''
• Lens type: high-quality glass lens optics

COLOUR SYSTEM

• Colour mixing: RGB + Warm White
• CCT: CCT control, + / - green correction, tungsten emulation
• White presets: 2.800 K - 8.000K
• Colour wheel: virtual colour wheel with macros
• Macros: several pre-built macros with adjustable speed

DYNAMIC EFFECTS

• Special features: linear crossfade channel from any white to any colour; virtual CTO on colours

BODY

• Hardware on-board: sockets for quick-Lock Omega bracket (clamp included)
• Pan range: 540°
• Tilt range: 250°
• Pan/Tilt resolution: 8/16bit
• Feedback: automatic repositioning after accidental movement
• Body: Die-cast aluminium
• Body colour: black

CONTROL

• Supported Protocols: DMX512, RDM, Art-Net, W-DMX
• DMX channels: 13 / 15 / 16 / 18 / 22 / 23 / 27channel
• Wireless Control: Included LumenRadio Timo Fx DMX/RDM receiver compatible with CRMX (Lumen Radio) and W-DMX (Wireless DMX)
• RDM: RDM for remote monitoring and settings
• Display: LCD high resolution colour display with autoflip
• Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: selectable dimming modes available
• Strobe / shutter: 1 - 30 Hz, electronic
• Display battery: self-charging battery backup
• Operating temperature: -10° ~ +45° Ta
• LED Control: flicker free frequency with adjustable PWM

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 240W
• Output (at 230V): 10 units on a single power line
• Power factor: >0,95

PHYSICAL

• IP rating: IP20
• Cooling: combination of heat pipe cooling system and low noise fan
• Suspension and fixing: any position with quick-lock omega brackets
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Data connection: Art-Net RJ45 IN/OUT
• Power connection: Seetronic powerCON waterproof IN/OUT connectors
• Dimensions (WxHxD): 308x448x230mm / 12.13''x17.64''x9.06''
• Weight: 13,6kg / 29.98lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM, cTUVus, FCC

BOX CONTENT

• 1 x PIXIEWASHXB
• 1 x 1,5 meters 3G1,5mmq power cable (BARE END - SEETRONIC POWERCON TRUE1 IP65 power connector)
• 2 x OS24PLUS
• User Manual
