PL Pixie ZoomXB, 280W RGBW, 7°-42°, IP65, schwarz

Pixie ZoomXB is a super bright single-source IP rated LED PAR featuring a 7° - 42° linear zoom and a fully homogenised output. Pixie ZoomXB is equipped with a proprietary 280W RGB + Warm White LED module which delivers a high-quality white reproduction with high CRI and TLCI parameters as well an extremely precise colour tuning. Pixie ZoomXB is an ideal solution for any application where users want a superior light quality but without the view of multi-cell fixtures. Being IP rated and offering a wide zoom range, the Pixie ZoomXB offers unprecedented flexibility and is a truly indispensable fixture for every rental company.

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 280W RGB + Warm White
• CCT: @full 6.000
• Luminous flux: (7°) 2'516 lm - (42°) 2'757 @Full
• Lux: (7°) 6'531 lx - (42°) 477lx @5 m full
• CRI: 91 @3.200 K; 88,6 @5.600 K
• R9: 80 @3.200 K; 82,5 @5.600 K
• TLCI: 80 @5.600 K
• TM30 Rf: 89 @3.200 K; 88 @5.600 K
• TM30 Rg: 108 @3.200 K; 108 @5.600 K
• Source life expectancy: > 30.000 h

OPTICS

• Zoom range: 7° - 42° motorised linear zoom
• Lens diameter: 125mm / 4.92''
• Lens type: high-quality glass lens optics

COLOUR SYSTEM

• Colour mixing: RGB + Warm White
• CCT: CCT control, + / - green correction, tungsten emulation
• White presets: 2.800 K - 8.000K
• Colour wheel: virtual colour wheel with macros
• Macros: several pre-built macros with adjustable speed

DYNAMIC EFFECTS

• Manual mode: manual adjustment of colour
• Auto mode: built-in programs with execution speed adjustment
• Special features: linear crossfade channel from any white to any colour; virtual CTO on colours

BODY

• Hardware on-board: on board mechanics for rigging to the ceiling
• Body: Sturdy die-cast aluminium body
• Body colour: black

CONTROL

• Supported Protocols: DMX512, RDM, W-DMX
• DMX channels: 5 / 7 / 11channel
• Wireless Control: Included LumenRadio Timo Fx DMX/RDM receiver compatible with CRMX (Lumen Radio) and W-DMX (Wireless DMX)
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: selectable dimming modes available
• Strobe / shutter: 1 - 30 Hz, electronic
• Display battery: self-charging battery backup
• Operating temperature: -20° ~ +45° Ta
• LED Control: flicker free frequency with adjustable PWM
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 265W
• Output (at 230V): 10 units on a single power line
• Power factor: >0,95

PHYSICAL

• IP rating: IP65 for temporary outdoor application, not for fixed installations
• Cooling: combination of heat pipe cooling system and low noise fan
• Suspension and fixing: bracket for hanging and positioning
• Signal connection: Seetronic XLR 5p IN/OUT connectors
• Power connection: Seetronic powerCON waterproof IN/OUT connectors
• Dimensions (WxHxD): 335x418x342mm / 13.19''x16.46''x13.46''
• Weight: 11,8kg / 26.01lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM

BOX CONTENT

• 1 x PIXIEZOOMXB
• 1 x 1,5 meters 3G1,5mmq power cable (BARE END - SEETRONIC POWERCON TRUE1 IP65 power connector)
• User Manual
