PL LumiPix 12QTour, LED-Bar, 12x10W RGBW, 25°, IP30, schwarz

LumiPix 12QTour is a 100 cm linear LED batten designed for professional use granting unprecedented chromatic performance. The super-slim design combined with its extreme colour precision and light output make LumiPix 12QTour a highly flexible and versatile solution for any kind of application or venue such as architectural, cyclorama, wall-washer, pixel effect or blinder.

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 12x10W RGBW LEDs
• Luminous flux: (15°) 3'657 lm - (45°) 3'630 @Full
• Lux: (15°) 2'901lx @5 m full
• Lux: (45°) 325lx @5 m full
• Source life expectancy: > 50.000 h

OPTICS

• Beam angle: 22,6°
• Field angle: 39°
• Lens diameter: 45mm / 1.77''
• Additional optics: 15° (opt) - 45° (opt)
• Other: on board magnetic frost holder

COLOUR SYSTEM

• Colour mixing: RGBW / FC
• Colour wheel: virtual colour wheel with macros
• Macros: several pre-built pixel macros with adjustable speed

DYNAMIC EFFECTS

• Pixel patterns: pre-programmed dynamic and static patterns
• Static mode: selection of static colour
• Manual mode: manual adjustment of colour
• Auto mode: built-in programs with execution speed adjustment

BODY

• Hardware on-board: sockets for quick-Lock Omega bracket (clamp not included)
• Body: Sturdy die-cast aluminium body
• Body colour: black

CONTROL

• Supported Protocols: DMX512
• DMX channels: 5 / 7 / 9 / 49channel
• Pixel control: pixel2pixel control
• Display: Graphic User Interface
• Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 7 selectable dimming modes available
• Strobe / shutter: 1 - 30 Hz, electronic
• Operating temperature: -10° ~ +45° Ta

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 100W
• Max power consumption (at 120V): 105W
• Output (at 230V): 30 units on a single power line
• Output (at 120V): 14 units on a single power line
• Power factor: 0,94

PHYSICAL

• IP rating: IP30
• Cooling: natural convection cooling enabled by a fanless design and a chassis engineered for passive heat dissipation
• Suspension and fixing: double hanging bracket suitable for safe hanging and for floor positioning
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Power connection: Seetronic powerCON IN/OUT connectors
• Dimensions (WxHxD): 994x138x70mm / 39.13''x5.43''x2.76''
• Weight: 5,4kg / 11.9lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM

BOX CONTENT

• 1 x LUMIPIX12QTOUR
• 2 x side floor brackets
• 1 x 1,5 meters power cable (BARE END - SEETRONIC power connector)
• User Manual
