SunRise 2FLXFC

The SunRise 2FLXFC re-imagines the classic two-light blinder as an IP65-rated all-rounder that can drench a stage, indoors or out, with vivid, fully-saturated RGBWW + Amber colour, yet glide seamlessly into the familiar amber-red glow of a DWE source as it dims.Driven by 2x independent 300 W RGBWW + Amber LED pods, each offering ± 20° manual pan, the SunRise 2FLXFC unleashes more than 32,000 lumens of output, making it the brightest full-colour blinder in the industry while maintaining high-CRI, dim-to-warm fidelity.Built on the proven SunBlast FLX chassis, its rugged die-cast magnesium housing inherits the same fast-lock, tool-free rigging system. Integrated locking connectors on every side let multiple fixtures snap together horizontally, vertically, or in mixed-axis arrays, so designers can build lines, matrices, or colour walls in minutes, whether standing on the floor or suspended from the included cam-lock yoke.From arena-filling pixels to sweeping audience blinders and wide, even stage washes, the SunRise 2FLXFC couples exceptional brightness with true modular flexibility, empowering lighting professionals to paint stages with colour, intensity, and imagination like never before.

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 2 x 300W RGBWW + Amber LED
• Luminous flux: (60°) 32'920 lm @Full
• Lux: (60°) 1'520lx @5 m full
• CRI: 92,8@ 3200K; 93 @ 5600K
• R9: 96,9 @ 3200K; 86 @ 5600K
• Source life expectancy: > 50.000 hrs (L70B10 @Ta 25° C / 77° F)

OPTICS

• Beam angle: 53°
• Field angle: 92°

COLOUR SYSTEM

• Spektra OS: unmatched color precision and consistency
• Colour mixing: RGBA + Warm White
• CCT: CCT control, + / - green correction, tungsten emulation
• White presets: 2.700 K ~ 10.000K

DYNAMIC EFFECTS

• Static mode: selection of static dimmer, colors and color temperature
• Manual mode: manual adjustment of colour
• Special features: tungsten emulation activation

BODY

• Bracket system: Several brackets available for simply array mounting - see available accessories
• Hardware on-board: fast ancor points on the front for accessory mounting and on board mechanics for modular assembly of multiple fixtures
• Pan range: +/- 20° with manual regulation
• Body: Weatherproof IP65 construction with die-cast magnesium alloy
• Body colour: black
• Other: pan directional adjustment for each pod

CONTROL

• Supported Protocols: DMX512, RDM, ArtNet, sACN (IGMP v2), CRMX (optional)
• DMX channels: several DMX modes from 1 ch to 35channel
• Modular Control Architecture (MCA): Modular and user-customizable DMX architecture
• Pixel control: pixel2pixel control
• Wireless Control: optional, LumenRadio Timo Fx DMX/RDM compatible with both CRMX (Lumen Radio) and W-DMX (Wireless DMX)
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: via DMX with UPBOXPRO (USB-DMX interface not included) or via Ethernet (Art-Net with DMX-Workshop)
• EtherFlow: Ethernet pass-through switch that preserves network connectivity even when the fixture is unpowered.

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 6 selectable dimming modes available
• Strobe / shutter: 1 - 30 Hz, electronic
• Operating temperature: -20° C / +45° C (-4° F / +113° F) Ta
• LED Control: flicker free frequency with adjustable PWM
• Selectable PWM: 1000 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 630W
• Standby power: 4,3 W
• Output (at 230V): 3 units on a single power line
• Power factor: > 0,94

PHYSICAL

• IP rating: IP65 for temporary outdoor application, not for fixed installations
• Cooling: active, silent operation
• Suspension and fixing: hanging bracket for floor stand. Also can fit the fast quick lock OMEGA bracket
• Signal connection: IP65 Seetronic XLR 5p IN/OUT connectors
• Data connection: IP65 Seetronic Art-Net RJ45 IN/OUT
• Power connection: Seetronic powerCON TRUE IP65 IN/OUT
• Dimensions (WxHxD): 542x173x192mm / 21.34''x6.81''x7.56''
• Weight: 9,9kg / 21.83lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, RCM, FCC, cTUVus

BOX CONTENT

• 1 x SUNRISE2FLXFC
• 1 x SBLFLXB01H
• 1 x OS25PLUS
• 1 x 1,5 meters 3G1,5mmq power cable (BARE END - SEETRONIC POWERCON TRUE1 IP65 power connector)
• User Manual
