PL EclFresnel 2KVW, 500W, 2700K-5600K, M.O., schwarz

The EclFresnel 2KVW is a powerful LED Fresnel lamp, designed as a replacement for a 2,000W fixture, with a bright and high-quality variable-white light, from 2,700K to 5,600K, using a 500W LED source. This is the perfect luminaire for those applications requiring high-quality white rendering, such as in TV studios, galleries, and virtual productions, with high CRI (>96), TLCI (>96), TM-30 and R9.The EclFresnel 2KVW has a manual zoom range from 15° to 79,5°, with precise focusing, and an 8-leaf barndoor (included).This fixture has an intuitive user interface with rotatory knobs. It also has stand-alone settings, PowerCon True in & through connections and XLR in & through, offering an incredible user experience and easy setup.

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 500W Variable White LED
• CCT: 2.700 K - 5.600
• Luminous flux: (15°) 12'196 lm - (79,5°) 19'711 @Full
• Lux: (15°) 6'782 lx - (79,5°) 1'118lx @5 m full
• CRI: 94 @WW; 96 @CW; 92 @full
• R9: 90 @WW; 88 @CW; 73 @full
• TLCI: 97 @WW; 99 @CW; 98 @full
• TM30 Rf: >94 @WW; >94 @CW; >93 @full
• TM30 Rg: <103 @WW; <103 @CW; <104 @full
• Source life expectancy: > 50.000 h

OPTICS

• Zoom range: 15° - 79,5° manual
• Lens diameter: 9.84" - 250mm / 0.39''
• Lens type: fresnel zoom lens

COLOUR SYSTEM

• Colour mixing: tunable white
• CCT: CCT control through dedicated DMX channel
• White presets: 2.700 K - 5.600K
• Colour wheel: built-in white presets

DYNAMIC EFFECTS

• Control Resolution: 16-bit dimmer
• Static mode: selection of static dimmer and color temperature
• Manual mode: manual adjustment of intensity and CT from knob
• Auto mode: built-in programs with execution speed adjustment

BODY

• Hardware on-board: filter frame, 8 doors barndoor, spigot
• Pan range: (for pole operated version) 360° with manual regulation
• Tilt range: (for pole operated version) 180° with manual regulation
• Body: Sturdy die-cast aluminium body
• Body colour: black (RAL9004), white finishing available (RAL9010)

CONTROL

• Supported Protocols: DMX512, RDM
• Stand Alone: 3 rotatory knobs
• DMX channels: 1 / 2 / 4 / 5 / 11channel
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 - 30 Hz, electronic
• Operating temperature: -20° ~ +45° Ta
• LED Control: flicker free frequency with adjustable PWM
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 450W
• Output (at 230V): 5 units on a single power line
• Power factor: > 0,95

PHYSICAL

• IP rating: IP20
• Cooling: combination of heat pipe cooling system and low noise fan
• Suspension and fixing: bracket for hanging and positioning
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
• Dimensions (WxHxD): 421x537x456mm / 16.57''x21.14''x17.95''
• Dimensions with PO system (WxHxD): 401x576x456mm / 15.79''x22.68''x17.95''
• Weight: 17,2kg / 37.92lbs
• Weight with PO system: 18kg / 39.68lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM

BOX CONTENT

• 1 x ECLFR2KVW
• 1 x ECLFR2KBD
• 1 x ECLFRSPG
• 1 x ECLFR2KTPG
• 1 x 1,5 meters 3G1,5mmq power cable (BARE END - NEUTRIK POWERCON TRUE1 IP65 power connector)
• User Manual
