PL LumiPix 12UQPro, LED-Bar, 12x8W RGBW, 19°, IP20, schwarz

LumiPix 12UQPRO is a 1 m long linear colour changer equipped with 12 high-efficiency RGBW/FC LED (8W each). The control system is customisable allowing section control and advanced possibilities in effect generation such as LED video or sound activated arrays.

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 12x8W RGBW LEDs
• Luminous flux: 2'436
• Lux: 1'884lx @3 m full
• Source life expectancy: > 50.000 h

OPTICS

• Beam angle: 20°
• Field angle: 36°
• Lens diameter: 38mm / 1.5''
• Additional optics: 45° (optional)

COLOUR SYSTEM

• Colour mixing: RGBW / FC
• Colour wheel: virtual colour wheel with macros
• Macros: several pre-built pixel macros with adjustable speed

DYNAMIC EFFECTS

• Static mode: selection of static colour
• Manual mode: manual adjustment of colour
• Auto mode: built-in programs with execution speed adjustment
• Sound mode: music activation through internal microphone and sensitivity control

BODY

• Body: Sturdy die-cast aluminium body
• Body colour: black

CONTROL

• Supported Protocols: DMX512
• DMX channels: 4 / 7 / 9 / 12 / 17channel
• Pixel control: 1 / 3 section control
• Wireless Control: Optional proprietary protocol compatible with WIFIBOX, WDBOX
• Display: LED display user interface
• Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
• IR: infrared sensor controlled by remote
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 - 28 Hz, electronic
• Operating temperature: 0° ~ +45° Ta
• LED Control: flicker free frequency with adjustable PWM

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 73,6W
• Max power consumption (at 120V): 71W
• Output (at 230V): 19 units on a single power line
• Output (at 120V): 7

PHYSICAL

• IP rating: IP20
• Cooling: natural convection cooling enabled by a fanless design and a chassis engineered for passive heat dissipation
• Suspension and fixing: double hanging bracket suitable for safe hanging and for floor positioning
• Data: USB port for USB WIFI transmitter (optional)
• Signal connection: XLR 3p + 5p IN/OUT connectors
• Power connection: Seetronic powerCON IN/OUT connectors
• Dimensions (WxHxD): 1000x56x168mm / 39.37''x2.2''x6.61''
• Weight: 3,3kg / 7.28lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM

BOX CONTENT

• 1 x LUMIPIX12UQPRO
• 1 x 1,5 meters power cable (BARE END - SEETRONIC power connector)
• User Manual
